Technical Features:
1. Double temperature probe to ensure the high repeatability of the sample temperature measurement.
2. The digital gas mass flowmeter automatically switches two gas flow rates, with fast switching speed and short
stability time.
3. Standard sample, convenient for customers to correct the temperature coefficient.
4. The instrument comes with an automatic calibration function.
5. Improve the installation process, and all adopt the mechanical fixation mode to completely avoid the pollution
of the differential heat signal by the colloid inside the furnace body.
6. The software adapts to the computer screen of each resolution, and the software automatically adjusts the
curve display mode according to the size of the computer screen. Support notebook, desktop computer,
support WIN2000, XP, WIN 7, WIN 8, WIN 10 and other operating systems.
7. Support user self-programming program, to achieve full automation of measurement steps. The software
provides dozens of instructions, the user can flexibly combine each instruction according to their own
measurement steps, and save. Complex operations are simplified to one-click operations.
8. Industrial level widescreen touch structure with rich display information, including set temperature, sample
temperature, oxygen flow, nitrogen flow, differential heat signal, various switching states, flow to zero.
9. USB communication interface, strong versatility, reliable signal without interruption, support self-recovery
connection function.
10. The furnace body structure is compact, the increasing and decreasing temperature rate can be arbitrarily
adjustable.
11. Optional refrigeration module, the lowest temperature up to-10℃ (suitable for materials which have low glass
transition temperature and melting point temperature, or having rapid cooling requirements).
Technical Parameters
| Model | ZG -DSC-800 |
DSC range | 0～±500mW |
temperature range | Room Temperature ~800℃ |
heating rate | 1~80℃/min |
temperature resolution | 0.01℃ |
temperature fluctuation | ±0.1℃ |
Temperature repeatability | ±0.1℃ |
DSC noise | 0.001mW |
DSC, resolution | 0.001mW |
DSC, definition | 0.01mW |
DSC, sensitivity | 0.001mW |
Temperature control mode | Heating up, constant, cooling down, and circulating temperature (automatic control of full program) |
Test mode | Glass transition temperature, Melting Temperature, enthalpy. |
Curve scan | Heating up scan |
Atmosphere control | The instrument switches automatically |
Display mode | 24bit color, 7-inch LCD touchscreen display |
Data interface | Standard USB interface |
Parameter standard | Equipped with a standard material (tin), the user can correct the temperature and heat enthalpy by itself |
Configuration
content | Quantity (set) |
Host Machine | 1 set |
Compact Disc | 1 PCS |
Data wire | 2 PCS |
Power line | 1 PCS |
Aluminum crucible | 1 pack (around 100 PCS) |
Ceramic crucible | 1 pack (around 100 PCS) |
Pure tin grain | 1 Bag |
10A fuse wire | 5 PCS |
Manual | 1 PCS |
Warranty sheet | 1 PCS |
Certificate of Compliance | 1 PCS |
Note: It is negotiable if other parts are needed.
Customers from University Labs:
1.Hebei University of Technology
2.Yanshan University
3.Xihua University
4.South China University of Technology
5.Hohai University
6.Nanjing Normal University
7.Southeast University
8.Nanjing University of Aeronautics and Astronautics
9.Yunnan Normal University
10.University of Electronic Science and Technology of China
11.Hebei University of Technology
12.Physic and Electrical Information College of Yunnan Normal University
13.Nanjing Normal University
Customers from Rubber Industry:
1.Fujian Hengjie Pipe Industry Co., LTD
2.Yadong Plastic (Chongqing) Co., LTD
3.Shandong Qufu Donghong Industrial Co., LTD
4.Shunming Pipeline (Nanjing) Co., Ltd
5.Shanxi New Super pipe industry Co., LTD
6.Shandong Huazhong (Qingdao) Environmental Technology Co., LTD
7.Shandong Longkou Nanshan Group
8.Jilin Songjiang Plastic Pipeline Co., LTD
9.Ningbo Anxin De billion pipe industry
10.Chengdu Yunlong Cable Material Co., LTD
11.Hubei Top Polymer Technology Co., LTD
12.Quanzhou Xingyuan Plastics Co., Ltd
13.Shandong Jufeng Plastic Industry Co., LTD
14.Jiangsu Huaxin Pan-Asia Co., LTD
15.Jiangsu Zhongtian Technology Co., LTD
16.Jiangsu Tongguang Group
17.Panjin Hang Seng Modified Materials Co., LTD
18.Shandong Luyu Plastic Industry Co., Ltd
Quality Inspect Institute:
1.Highway Research Institute of Beijing Ministry of Communications
2.Chongqing Research Institute of Quality Measurement and Testing
3.Daqing Quality Inspection Institute
4.Dalian Lantian Quality Inspection Institute
5.Baoding Shunping County Quality and technical supervision Bureau
6.Zhejiang Provincial Environmental Protection Science Design and Research Institute
7.Wuhan Quality Inspection Institute, 8.Jiangxi Province Building Materials Research and Design Institute
9.Beijing Industrial Injury and Occupational Hazard Prevention Center
10.Tianhua Chemical Machinery and Automation Research and Design Institute
11.Farmland Irrigation Research Institute, Chinese Academy of Agricultural Sciences
