Introduction To Titrator
Measuring range: ±2,000mV/±20.00pH, with a wide measuring range to meet multi-dimensional experimental needs.
Resolution: 0.1 mV / 0.001 pH, accurately capture potential changes, suitable for a variety of complex sample analysis.
Burette capacity: 10mL (optional 1mL/5mL/50mL module), flexible adaptation to different experimental scales.
Feature highlights
Intelligent endpoint determination: Automatically calculate and identify titration jumps to avoid manual misjudgment and improve detection efficiency.
Multi-task mode: Supports 6 modes such as acid-base titration and redox titration, one machine for multiple uses.
Compliance guarantee: Audit tracking + electronic signature function, in line with GMP/GLP certification requirements, to ensure data integrity.
Our Titrator Products
Advantages Of Our Products
Conform to the GMP specifications, and the titration results meet the GLP requirements.
Enhanced Safety Features
Leak detection and automatic shutdown protection
Chemical-resistant materials throughout fluid path
Product Applications
Pharmaceutical Analysis
- Content determination of active pharmaceutical ingredients
- Quality control of drug formulations
- Water content testing (Karl Fischer method)
- Stability testing of pharmaceutical products
Food Quality Testing
- Acidity analysis of beverages and dairy products
- Peroxide value determination in edible oils
- Salt content measurement in processed foods
- Sulfur dioxide detection in food additives
Petrochemical Industry
- TAN/TBN analysis of lubricants
- Sulfur content testing in fuels
- Additive analysis in petroleum products
Environmental Monitoring
- COD determination in water samples
- Heavy metal content analysis
- Chloride ion concentration testing
- Calcium and magnesium ion content, total hardness
Chemical Manufacturing
- Raw material purity analysis
- Acid-base concentration measurement
- Surfactant content determination
- Total amine value, epoxy value, epoxy equivalent of epoxy resin and curing agent
NCO content of other materials
Research & Education
- Analytical method development
- Chemistry teaching experiments
Drug Development And QC Testing
- Purity analysis of raw materials: such as alkaloid and amino acid content determination, to help control drug quality.
- Precise control of injection pH value: to ensure drug stability and safety.
- Pharmacopoeia routine item testing: such as chloride, sulfate, etc., to meet regulatory requirements.
Food Safety Monitoring
- Edible oil acid value/peroxide value detection: ensure the quality of edible oil and meet food safety standards.
- Determination of calcium ion content in dairy products: ensure accurate nutritional ingredients and meet health needs.
- Quantitative analysis of sweeteners in beverages: ensure the compliance of food additives.
Environmental And Chemical Testing
- Fast determination of COD in industrial wastewater: Assist environmental monitoring and timely grasp of pollution conditions.
- Monitoring of metal ion concentration in electroplating solution: Ensure the stability of electroplating process.
- Analysis of lithium battery electrolyte composition: Assist the development of new energy industry.
Application Cases
Determination of iodine content in salt by GT90 potentiometric titrator
Reagents:
| Titrant: 0.1mol/L sodium thiosulfate standard solution | Sample: salt |
| Potassium iodide: 50g/L | Phosphoric acid: 1mol/L |
Determination method:
Weigh about 5g of the sample, weigh it accurately, place it in a titration cup, add 50mL of water to dissolve it, then add 2mL of phosphoric acid solution and 5mL of potassium iodide solution. Mix thoroughly, and titrate to the endpoint using a sodium thiosulfate standard titration solution (0.1mol/L) on an automatic titrator.
Reference standards:
GB/T 5461-2016 Edible salt
GB/T 13025.7-2012 General test method for salt industry Determination of iodine
Potentiometric titration sample determination record
Sample source: customer supplied
Ambient humidity: 52%
Ambient temperature: 28 ℃
| Sample measurement record (iodine content in salt) | ||||||||
| Determination order | Sample size | End point volume | Blank volume | Iodine content (mg/kg) | ||||
| 1 | 3.36g | 0.09ml | 0.05ml | 26.25 | ||||
| 2 | 3.22g | 0.09ml | 0.05ml | 25.18 | ||||
| Analysis duration | About 2 mins | Experimental results Average iodine content | 25.72 | |||||
Potentiometric titration sample determination record
Experimental conclusion: The iodine content in salt was determined to be 26.25mg/kg and 25.18mg/kg respectively. The average content was 25.72mg/kg.(All experimental processes and results are automatically recorded in the system)
Partners
Let's Connect
Ideal for work scenarios requiring speed, accuracy, and automation, our titrator streamlines workflows while delivering professional-grade results. If you are interested in our products, please leave your contact information.
